| Architecture: | SAR |
| Brand: | Analog Devices |
| Development Kit: | EVAL-AD7328SDZ |
| DNL - Differential Nonlinearity: | -0.9 LSB/1.5 LSB |
| Factory Pack Quantity: Factory Pack Quantity: | 1000 |
| Gain Error: | +/-7 LSB |
| INL - Integral Nonlinearity: | +/-1.1 LSB |
| Input Type: | Differential/Pseudo-Differential/Single-Ended |
| Input Voltage: | 10 V, +/-2.5 V/+/-5 V/+/-10 V |
| Interface Type: | Microwire, QSPI, SPI |
| Manufacturer: | Analog Devices Inc. |
| Maximum Operating Temperature: | +85 C |
| Minimum Operating Temperature: | -40 C |
| Mounting Style: | SMD/SMT |
| Number of ADC Inputs: | 8 Input, 4 Input/7 Input, 4 Input |
| Number of Channels: | 8 Channel |
| Number of Converters: | 1 Converter |
| Operating Supply Voltage: | 5 V, 15 V |
| Package / Case: | TSSOP-20 |
| Pd - Power Dissipation: | 29 mW |
| Power Consumption: | 21 mW |
| Product Category: | Analog to Digital Converters-ADC |
| Product Type: | ADCs-Analog to Digital Converters |
| Reference Type: | External, Internal |
| Resolution: | 12 bit |
| Sample and Hold: | Yes |
| Sampling Rate: | 1 MS/s |
| Series: | AD7328 |
| SNR - Signal to Noise Ratio: | 76 dB |
| Subcategory: | Data Converter ICs |
| Supply Voltage - Max: | 5 V, 15 V |
| Supply Voltage - Min: | 5 V, 15 V |
| Type: | S/H ADC |
| Architecture | SAR |
| Automotive | No |
| Converter Type | General Purpose |
| Digital Interface Type | Serial(SPI, QSPI, Microwire) |
| ECCN (US) | EAR99 |
| EU RoHS | Compliant |
| Full Scale Error | ±7LSB |
| Input Signal Type | Single-Ended|Pseudo-Differential|Differential |
| Input Type | Voltage |
| Input Voltage | 10V|±2.5V/±5V/±10V |
| Integral Nonlinearity Error | ±1.1LSB |
| Lead Shape | Gull-wing |
| Maximum Operating Temperature (°C) | 85 |
| Maximum Power Dissipation (mW) | 31 |
| Maximum Supply Current | 0.41 |
| Minimum Operating Temperature (°C) | -40 |
| Mounting | Surface Mount |
| No Missing Codes (bit) | 12+Sign |
| Number of ADCs | 1 |
| Number of Input Channels | 8|4/7|4 |
| Packaging | Tape and Reel |
| Part Status | Active |
| PCB changed | 20 |
| Pin Count | 20 |
| Polarity of Input Voltage | Unipolar|Bipolar |
| PPAP | No |
| Process Technology | iCMOS |
| Resolution | 13bit |
| Sample and Hold | Yes |
| Sampling Rate | 1Msps |
| Signal to Noise Ratio | 76dB(Min) |
| Single-Ended Input | Yes |
| Standard Package Name | SOP |
| Supplier Package | TSSOP |
| Typical Dual Supply Voltage (V) | ±15/3|±15/5 |
| Typical Power Dissipation (mW) | 21 |
| Voltage Reference | Internal|External |
| Voltage Supply Source | Dual |
| Вес, г | 0.19 |
